Cadre et plus
Taille:
S,M,L,XL
Max loadable weight (KG):
120 kg
Front Fork Type:
Suspension
Suspension Type:
Fully
Travel Front:
170 mm
Fourche:
Rockshox, ZEB Ultimate Charger 3.1 RC2 170 mm
Cadre:
Overvolt GLPIII Full carbon Ultimate, Carbone, Homme
Amortisseur:
Rockshox, Vivid Air Ultimate 205×65 mm Trunnion/15×8 mm
Cintre et Selle
Handlebar Diameter:
35 mm
Handlebar Material:
Aluminium
Handlebar Rise:
30
Handlebar Width:
800 mm
Seatpost Material:
Aluminium
Seatpost Travel (mm):
125 mm,150 mm,170 mm
Stem Length:
35 mm,45 mm
Poignée:
Lapierre, Grips, small diameter
Cintre:
Renthal, Flat bar, Fatbar, Rise: 30 mm, Ø: 35 mm
Jeu de direction:
Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Selle:
Selle Royal, Terra Ridon X3 145mm Kium Mobius
Tige de Selle:
Sram, Dropperpost, Reverb AXS, Ø: 31.6mm, travel: 125 mm
Potence:
Renthal, Apex, Ø: 35 mm, L: 33 mm
Composants E-bike
Battery Capacity:
800 Wh
Battery Location:
Downtube
Motor Torque [nm]:
85 Nm
Motor Location:
Center
Batterie:
Bosch, Powerpack 800Wh
Chargeur:
Bosch, Quick Charger, Charger 4A
Ecran:
Bosch, KIOX 300 + Mini Remote
Moteur:
Bosch, Performance line CX-RACE
Géométrie
Bottom bracket drop [mm]:
10 mm
Chain stay length [mm]:
440 mm
Fork offset [mm]:
600 mm
Fork total length [mm]:
44 mm
Head tube angle:
64 degrees
Head tube length [mm]:
110 mm,120 mm,130 mm,140 mm
Reach [mm]:
435 mm,460 mm,480 mm,505 mm
Stack [mm]:
629 mm,638 mm,647 mm,656 mm
Seat tube angle:
77 degrees
Seat tube length [mm]:
390 mm,400 mm,430 mm,460 mm
Top tube length [mm]:
580 mm,607 mm,629 mm,656 mm
Wheelbase [mm]:
1225 mm,1255 mm,1279 mm,1308 mm
Roues et composants de roues
Wheelset Material:
Carbone
Pneu:
Schwalbe, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, TR, 62-622
Pneu Arrière:
Schwalbe, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
Paire de Roues:
Lapierre, eAM+ carbon, 622×30, J-bend Tubeless ready, 15×110 mm
Roue Arrière:
Lapierre, eAM+ carbon, 584×33 J-bend Tubeless ready, 12×148 mm
Taille de Roue:
29, 27.5
Système de freinage
Brake Rear Mount:
Post Mount
Frein Avant:
Sram, Frein à disque hydraulique, Maven Ultimate 4 pistons, 220 mm
Frein Arrière:
Sram, Frein à disque hydraulique, Maven Ultimate 4 pistons, 200 mm
Levier de frein:
Sram, Maven Ultimate-BL
Disques de frein:
Sram, HS2 220 / 200 mm, 6 bolt Disc
Transmission
Cassette Teeth:
10-52T
Crankset Teeth:
34T
Crankset Type:
single
Number Of Gears:
12
Cassette:
Sram, Cassette, XS1295 T-TYPE-12, XD
Chaîne:
Sram, Chaîne, XO T-TYPE Powerlock 12s
Guide chaîne:
Lapierre, 1x
Pédalier:
E Thirteen, Race Carbon + SRAM XX T-TYPE 55CL
Dérailleur Arrière:
Sram, X0 Eagle AXS T-TYPE, 12s
Vitesse:
Sram, Derailleur
Pédales:
XLC, by VP
Selecteur de vitesse Gauche:
Sram, Triggershift, AXS Pod Ultimate 12s
Selecteur de vitesse Droit:
Sram, Triggershift, AXS Pod Ultimate 12s
