Cadre Orbea Terra Hydro disc, hydroformed triple butted aluminium, tapered 1-1/8″ – 1,5″, BB 68mm – BSC English, Thru Axle 12mm x 142mm rear, thread M12x P1.5, DT internal cable routing, 27,2mm seat tube, MMS system
Fourche Orbea Terra OMP carbon disc fork, full carbon steerer, tapered 1-1/8″ – 1,5″, carbon dropouts Thru axle 12mm x 100m, thread M12xP1.5, MMS system
Plateau de pedalier Shimano GRX RX600 30x46t
Direction FSA 1-1/8 – 1-1/2″ Integrated Carbon Cup ACB Bearings
Cintre OC1 All Road, reach 80mm, drop 125mm, flare 12º
Potence OC1 31.8mm interface -6º
Manettes Shimano ST-RX600
Freins Shimano RX400 Hydraulic disc
Pignon Shimano 105 R7000 11-34t 11-Speed
Derailleur arrière Shimano RD-RX810
Derailleur avant Shimano GRX RX810
Chaine Shimano HG 601
Roues Orbea wheel: Ready GR with 12mm E-Thru hubset Shimano RS470 28H
Pneus Vittoria Terreno Dry Gravel G2.0 TNT 700x38c
Pedale N/A
Tige selle OC2 27.2 Offset 20
Selle Selle Royal Seta RS
Guidoline Orbea Eva
Blocage Avant Orbea Thru Axle 12x100mm M12xP1.5 Hollow
Blocage Arrière Orbea Thru Axle 12x142mm M12xP1.5 Hollow
